mini excavator

  • Product Classification: mini excavator
  • Definition: small excavator can work in narrow spaces for garden uses such as digging holes for trees or clearing land, digging pond etc.
  • Contact Us Now
Product Details
Product inquiry

Small excavator would be the best around a small farm. They are sometimes called compact excavators, mini diggers or micro excavators.

Please choose the right excavator according to your needs.

Model

HMB12

HMB15

HMB17

HMB18

HMB20

Bucket Volume

0.025m³

0.025m³

0.045m³

0.045m³

0.045m³

Working Type

backhoe

backhoe

backhoe

backhoe

backhoe

Track length

1235mm

1235mm

1450mm

1450mm

1450mm

platform ground clerance

380mm

380mm

437mm

420mm

437mm

Chassis Width

930mm

946mm

1130mm

1120mm

1130mm

Track width

180mm

180mm

230mm

230mm

230mm

Track height

320mm

320mm

320mm

320mm

320mm

transportation length

2550mm

2550mm

3160mm

3230mm

3160mm

Overall Height

2195-1330mm

2195-1330mm

2377mm

2360mm

2377mm

Control Valve

KDK(Italy)

NHI

NHI

NHI

TRM

Swing Motor

Eaton(USA)

Eaton(USA)

Eaton(USA)

Eaton(USA)

Eaton(USA)

Engine Type

KOPU192

Yanmar  3TNV70

Yanmar  3TNV70

Yanmar  3TNV70

Yanmar  3TNV70

Power

12

13.6

13.6

13.6

13.6

Swing Radius

1190mm

1190mm

1440mm

1440mm

1440mm

Digging Height

2490mm

2490mm

3275mm

3258mm

3275mm

Unloading Height

1750mm

1750mm

2310mm

2293mm

2310mm

Digging Radius

2400mm

2400mm

3560mm

3513mm

3470mm

Digging Depth

1320mm

1320mm

1740mm

1757mm

1740mm

Dozer Blade Ligting Height

325mm

325mm

262mm

262mm

262mm

Operating weight

1000kg

1100kg

1600kg

1700kg

1900kg

Max. digging depth

1400mm

1400mm

2150mm

2167mm

2150mm

Travel Motor

Eaton(USA)

Eaton(USA)

Boden

PMC(Korea)

PMC(Korea)

Hydraulic Pump

KDK(Italy)

KDK(Italy)

KDK(Italy)

KDK(Italy)

KDK(Italy)

Products video

what are the most important advantages of mini excavators?
Lower cost and more convenient transportation
Easy to maintain
Low requirements for driver skills
Cheaper hardware
In addition to demolishing large buildings, contractors on construction sites are increasingly using mini excavators. From grabs, drills to hydraulic breakers, many innovative accessories can be installed on the boom.

How to choose the right mini excavator?
Size and weight are the first and most important factors you need to consider. The first step is to look at the plans and tasks that you or your employees will implement and complete with the excavator. If the operating space provided on the job site is limited or on an unstable ground, the lighter option should be selected. If the construction site is located in a larger building, you will need to collect information about the size of the potential entry point, which is also likely to be a limiting factor.
If you plan to use a hydraulic breaker, you need more weight to create a strong foundation that can withstand the impact. While the construction area has more space, larger and heavier machines are also needed to eventually speed up.
Although these devices can only be learned in a few hours at most, hiring well-trained operators is the key to achieving maximum efficiency. Experienced experts have the necessary knowledge to operate the machine in unexpected situations.


Service&warrantly
1. One-stop service, producing all kinds of hydraulic hammers and excavator accessories, such as quick hooks, grabs, compactors, augers, rippers, etc...
2. Provide free customized services. We have a professional design team to meet any of your requirements. At the same time, we can provide intimate pre-sales and after-sales services.
3. Sign a confidentiality agreement regarding product information.
4. The product will be tested before leaving the factory.
5. Fast delivery service
6.We provide free replacement and maintenance services within one year.
